Epotel LM
High-Performance, Fast-Curing Smooth Epoxy Line Marking
Coverage

160/ft² (14.86/m²) per Gallon @ 10.00 mils (0.2540 mm)

NMS
09 67 00
Description

Epotel LM is a two-component, 100% solids, solvent-free, fast-curing liquid-applied epoxy line marking and safety area coating. Epotel 100 LM is ideal for applying lines in areas where there is a heavy workload. Epotel 100 LM is a highly visible and long-lasting epoxy coating with excellent coverage that reduces application steps. It is a time- and cost-effective solution to indicate safe traffic management plans. Epotel 100 LM is designed to provide a high build, tough, durable, abrasion- and chemical-resistant coating for interior concrete floor surfaces.

Advantages
  • 100% solids, zero VOCs, odourless
  • Fast curing: 8 hours to vehicular traffic
  • CFIA approved, USDA accepted
  • Easy to apply, self-leveling properties
  • Chemical and abrasion resistant
  • Blush resistant, high-gloss finish
  • Excellent coverage, seamless finish
Uses

Epotel LM is ideal for:

  • Roads, car parks, warehouses and industrial floors
  • Quick turn-around projects
  • Cold temperature applications
  • Industrial floors or other environments requiring clean, sanitary conditions
  • Light-to-medium industrial, commercial and manufacturing applications
Physical Properties

Colour

Yellow, Red, Blue, Green, White, Black

Resin Type

Epoxy

Coverage
  • 43 ft²/L (160 ft²/gal) @ 10 mils DFT
  • 258 Liner feet of 50mm/ Liter @ 10 mils DFT
  • Note: 2 coats required; total thickness: 10 mils per coat
Mix Ratio
  • Part A : Part B
  • 3:1 by volume
Cure Time @ 23°C (75°F)
  • To touch: 1-2 hours
  • Light traffic: 6 hours
  • Vehicular traffic: 8 hours
  • Fully cured: 7 days
Cure time @ 5°C (41°F)
  • To touch: 6 hours
  • Light traffic: 24 hours
  • Vehicular traffic: 36 hours
  • Fully cured: 14 days
Pot Life – working time @ 23°C (75°F)

5 - 10 minutes

V.O.C,

Zero



Performance Properties
Method Results
Percent Solids

ASTM D7232

100%

Viscosity (Brookfield) 23-30°C (75-85°F)

ASTM D2196, Part A + B

1,500 (pigmented)

Compressive Strength

ASTM 695

75 MPa (10,900 psi)

Tensile Strength

ASTM 695

61 MPa (8,900 psi)

Tensile Modulus

ASTM D638

3.3 MPa (480 psi)

Elongation

ASTM D638

8.0%

Flexural Modulus

ASTM D790

3.8 MPa (556 psi)

Abrasion Resistance

ASTM D4060

0.033

Mar Resistance

ASTM D5178

1.5 kg

Shore D Hardness

88

60° Specular Gloss

110

Chemical Resistance

Durex® Epotel LM – resists damage by chemical reactivity and/or solvent reaction. Contact Durabond Technical Services for additional information.
